I128_07 10 x 10 x 2.2 mm Carbide Insert, 30-Degree Bevel

Name: I128_07 10 x 10 x 2.2 mm Carbide Insert, 30 Degree
SKU: I128_07
Price: 5.60 USD
Availability: InStock

$5.60

The I128_07 listing gives 10 x 10 x 2.2 mm dimensions, a 30-degree bevel and Taiwan origin.

SKU: I128_07 Category: Helical Cutterheads & Inserts

Description
Additional information

I128_07 is the smallest square insert in this group. The listing gives a 10 x 10 x 2.2 mm body, a 30-degree bevel and Taiwan origin. The drawing identifies the dimension order as length, width, thickness and slope. It shows a center hole, but does not label the hole or mounting-seat dimensions.

Specifications

Product type	Carbide insert (product title)
Length x width x thickness	10 x 10 x 2.2 mm (source drawing)
Bevel	30 degrees (source drawing)
Origin label	Taiwan (title and drawing)
Center hole	Visible; diameter is not stated

Check the 10 mm insert face

The face size is 10 x 10 mm, with a listed thickness of 2.2 mm. Compare those values and the 30-degree bevel with the cutter-body drawing. The gallery shows one center hole, but its diameter and the required screw are not listed. Confirm both before fitting.

Before fitting this insert

Check length, width and thickness against the cutter drawing.
Confirm the required bevel is 30 degrees.
Verify the hole and seat dimensions with the toolmaker.
Make sure the insert sits flat before use.

Listing limits

The page does not name a compatible cutter body, screw, hole diameter, carbide grade or coating. It also gives no speed or feed data. Use the drawing for the outside dimensions and confirm the mounting details separately.
