TR4752 – V-Groove Router Bit (12mm Shank)
Price range: $4.37 through $45.85
TR4752 V-groove router bit with 12mm shank. Ideal for woodworking frames, engraving, lettering, and decorative slotting, delivering sharp, precise cuts with durable performance.
V-Groove Router Bit for Woodworking Frames and Engraving (12mm Shank)
Precision V-groove bit made of tungsten steel alloy with heat-resistant coating and sealed bearings. Ideal for engraving, chamfering, sign-making and decorative V-cuts on solid wood, MDF and plywood.
Features
- Tungsten steel alloy cutting head for wear resistance
- High-temperature & heat-resistant Teflon coating
- ±0.003″ tolerance for crisp V-grooves
- Sealed, lubricated bearings for smooth operation
- Clean engraving/chamfering on solid wood, MDF, plywood, etc.
Specifications
- Name: V-shaped router bit
- Item: 12mm Shank Router Bit
- Material: Tungsten steel alloy
- Shank Diameter: 12mm
- Applicable Materials: Solid wood, ecological board, MDF, plywood, etc.
- Applicable Equipment: Trim router, engraving machine, hand router, CNC, etc.
- Recommended Feed Speed: 8–12 m/min
- Recommended Spindle Speed: 18,000–24,000 RPM
- Tolerance: ±0.003″
- Bearings: Sealed & lubricated
Package Includes
- 1 × router bit
Notes
- Your preferred color will be shipped; substitutes may be provided if out of stock.
- Manual measurement may vary by 1–3 mm.
- Colors may differ slightly due to display settings and photography.
Reference Data
| Machine | Speed | Type | Notes |
|---|---|---|---|
| Trim router | 10,000–30,000 rpm | Electric router | 1st 9,000 rpm; 2nd 12,000 rpm; 3rd 15,000 rpm; 4th 19,000 rpm; 5th 23,000 rpm |
| Vertical milling router | 12,000–24,000 rpm | CNC engraving machine | Variable frequency up to 18,000 rpm |
| Diameter / Cutting Height (mm) | Max Speed (RPM) | Max Feed Speed (mm/min) |
|---|---|---|
| ≤ 25 | 24,000 | 5,000 |
| 25.1 – 35 | 18,000 | 4,000 |
| 35.1 – 50 | 16,000 | 3,500 |
| 50.1 – 60 | 14,000 | 3,000 |
| 60.1 – 80 | 12,000 | 2,500 |
| ≥ 80 | 10,000 | 2,000 |
| type | 12mm shank – Rack Mounted V-Shaped Bit 12 x 16.8mm, 12mm shank – Rack Type V-Shaped Bit |
|---|
